struct Dqs_fix {
    // A bone is defined as a segment (origin, direction and length in 3D space)
    std::vector<anim::Bone> _bone_rest_pose;
    // _weights[vertex Index] == map<bone_index, bone_skinning_weight>
    std::vector< std::map<int, float> > _weights;

    /// Bulging-free dual quaternion skinning
    /// "YoungBeom Kim andJungHyun Han"
    inline Vec3 apply(
            int id, // Index of the vertex we correct
            const Point3& rest_vert, // Vertex position at bind pose / T pose
            const Point3& dq_in, // Vertex after dual quaternion skinning
            const std::vector<Mat4x4> skinning_transfo) // Global transformation for each joint
    {
        // find the index of the bone with the highest weight for vertex id
        int major_bone = anim::find_max_index(_weights[id]);

        // Find out the distance to the bone in rest pose and after skinning.
        const anim::Bone& bone_rest = _bone_rest_pose[major_bone];
        float dv_rest = bone_rest.dist_from_segment(rest_vert);

        const anim::Bone bone_current = bone_rest.transform(skinning_transfo[major_bone]);
        float dv_current = bone_current.dist_from_segment(dq_in);

        Vec3 result = dq_in;

        // If dv has grown then bulging is detected so we draw the vertex towards
        // the closest bone point.
        if (dv_current > dv_rest)
        {
            Point3 proj_point = bone_current.project_on_segment(dq_in);
            Vec3 proj_dir  = dq_in - proj_point;
            const float  factor = dv_rest / dv_current;
            result = proj_point + (factor * proj_dir);
        }
        return result;
    }

};

// -------------------------------------------------------------------------

/// Finds the max index in a weight map.
int find_max_index( const std::map<int, float> >& weights)
{
   auto it = weights.begin();
   auto maxit = weights.begin();
   float max = 0.f;
   for( ;  it != weights.end(); ++it) {
        if (it->second > max)
        {
            max = it->second;
            maxit = it;
        }
    }
    assert(maxit->second == max);
    return maxit->first;
}

// -------------------------------------------------------------------------

float Bone::dist_from_segment(const Point3& p) const {
    Vec3 op = p - _org;
    float x = op.dot(_dir) / (_length * _length);
    x = fminf(1.f, fmaxf(0.f, x));
    Point3 proj = _org + _dir * x;
    float d = proj.distance_squared(p);
    return sqrtf(d);
}

// -------------------------------------------------------------------------
Point3 Bone::project_on_segment(const Point3& p) const
{
    const Vec3 op = p - _org;
    float d = op.dot(_dir.normalized()); // projected dist from origin

    if(d < 0)            return _org;
    else if(d > _length) return _org + _dir;
    else                 return _org + _dir.normalized() * d;
}
